Pinball Designer
An All-In-One Pinball Making Toolset
With Pinball Designer, quickly explore designs and layouts Virtually. Program logic for LCD display, Gameplay, Modes, Multiballs. Export to a Physical game with the press of a button. See it in action.
Quick Iteration
Get up and running with drag and drop components. Place flippers, draw custom ramps, test your layout in real-time. If it something isn't working, delete or start over.
Simple Programming
Extremely simple programming. Add rules for what activates playfield multipliers. Use standard mode rules or program your own specific. Trigger sounds, animations, light shows upon specified events.
Not Just Virtual
Pinball Designer is not just a virtual pinball design tool. It was created with a manufacturing mindset. This is a tool to design, program and bring mass produced physical games to market.
Under The Hood
Underside of playfield management. Every item including lights and flippers will auto place underside mechanisms and circuitry. Rotate items and circuit boards to fit your game.
Wire It Up
Create wire cabling routes between circuit boards, lights and coils. These wires generate configuration data to communicate with hardware in a physical game.
Bring it to life
With the press of a button, all the data to cut a wooden playfield, cut metal ramps, bend wireforms can be exported to assemble your game.
Pricing
Pinball Designer is a low-priced piece of software, but it comes with many customized upgrade fees when it comes to building physical games. Start here by purchasing the base software which allows you to design and program virtual pinball machines.
If you wish to take your game into a physical product, there is a wide range of individual components you can purchase.
*Items in red are not currently ready for sale to end-users
Circuit Boards: $200-$250 This includes all boards necessary to control your game. Price depending on how many lights and coils you have in your game. Flawless integration with Pinball Designer. What you see happening in the virtual Pinball Designer is exactly what you will see happen in the physical game (flippers and mechs, lights, LCD animations, gameplay code).
G-Code Files: $100 This includes main cut, pilot hole top, and pilot hole bottom. Take your g-code file to a local CNC shop or cut yourself.
Playfield Cut: $250 We cut your playfield for you and ship. G-Code files are free.
Playfield Print: $120 Most companies use a direct to playfield print with a clear coat. I do not support this method. I use a method with a poster print glued to the playfield and a plastic sheet applied to protect graphics. The inserts are cut out of the wood and printed art, so this cost includes your printing, cutting, glue and light diffusers. This allows any shape light insert to be cut. Click here for Comparison.
Wire Cabling: $100 Straight cut, stripped and sorted cable assemblies. Crimp and assemble on your own. +$120 Complete plug and play cabling.
Ramp Cut: $100 This is a fee per ramp to have it made.
Wireform: $60-$120 This is a fee per wireform to have it made. $60 for 3D printed joint snaps. $120 for welded wireform.
Playfield Cabinet: $500-$550 Choose between 1/2" re-inforced cabinet vs 3/4" standard. The upside to a slightly thinner cabinet is that it is easier to handle and cheaper to ship.
Cabinet Art: $120 Waterproof, heavy duty poster print.
Click here for Comparison.
Complete Backbox: $450 This includes a fully assembled backbox with plastic trim, speaker grill, speakers installed, LCD, a key and your artwork.
(above items combined estimated: $2,350)
______________________________________________________
Parts you still need: (estimated $1,000)
Mechanical parts and coils: You will have the choice to source our parts or current parts via a pinball parts distributor. Entire bill of materials parts can be viewed from within pinball designer.
Coin Door(optional), Lockdown Bar, Cabinet Trim, Glass Start and Flipper Buttons
Legs, Leg Brackets, Screws, Power Supply
Assembly Fee: $1000 Purchase everything above + Additional Parts. We will assemble and build your game at the press of a button and ship it out.
